Rexroth 1322501000
Cylinder Actuator

Emerson’s innovative pneumatic solutions from AVENTICS (formerly Bosch Rexroth Pneumatics) provide precise and long-lasting operation for your machine automation applications. With a compact design and low-maintenance technology to actuate machinery, their pneumatics can be trusted to deliver reliable and efficient operation even in the most demanding applications and environments.

The AVENTICS Series ICM is a mini cylinder and cost-efficient solution for high corrosion resistance and reliability even in harsh environments. The cylinder tube and piston rod are made of stainless steel, the cylinder covers are fashioned from a high-quality polymer.

Mini cylinder, Series ICM

– 8 mm

– Ports M5

– Double-acting

– Cushioning elastic

– Corrosion-resistant

– With integrated rear eye

– Piston rod external thread

– Suitable for use in food processing

Technical Specifications

Manufacturer: Emerson Aventics
Type: Mini Cylinder

Series: ICM

Acting principle: Double Acting

Medium: Compressed Air

Ambient Temperature Max (DegC): 70

Ambient Temperature Min (DegC): -20

Working Pressure Max (Bar): 10

Working Pressure Min (Bar): 2

Pneumatic port: G 1/8

Stroke (mm): 12

Max. particle size: 50 m

Oil content of compressed air min.: 0 mg/m

Piston diameter: 25 mm

Piston rod thread: 25; M10x1

Scraper: Standard Industrial Scraper

Materials

Connection thread: Stainless Steel

Seal Acrylonitrile: Butadiene Rubber

Nut for Cylinder: Mounting Polyamide

Nut for Piston Rod: Stainless Steel

Scraper: Polyurethane
