CKD SSD2 Series D/A Pneumatic Cylinder

Space saving series with a wide range of stroke lengths and switch mounting surface options compared with conventional models.
A widely varied series of space-saving cylinders, suitable for everything from general environments to specific applications.

Bore size mm – 32
Actuation – Double acting
Working fluid – Compressed air
Max. working pressure MPa – 1.0 (150 psi, 10 bar)
Min. working pressure MPa – 0.1 (15 psi, 1 bar)
Proof pressure MPa – 1.6 (230 psi, 16 bar)
Ambient temperature C – -10 (14F) to 60 (140F) (no freezing)
Port size – Rc1/8 *1
Stroke tolerance mm With rubber cushion – +2.0
Stroke tolerance mm Without cushion – +1.0
Working piston speed mm/s – 50 to 500
Cushion – With or without cushion can be selected
Lubrication – Not required (use turbine oil class 1 ISO VG32 if necessary for lubrication)
Allowable absorbed energy J With rubber cushion – 0.16
Allowable absorbed energy J With rubber cushion – 0.025
Weight – 652g

*1: The 32 bore size with a 5 mm stroke and without a switch has a port size of M5.
